Summary
Original plot of the corrected Rise Mode 7 implementation, ticket 1196, October 14 2026. X is signed one-second headwind change measured from timestamped world-wind vectors; Y is local-vertical wind including the gusts used by flight physics. Source: GpwsWindshear.h. Purple identifies retained Rise numerical thresholds, not a validated Honeywell performance envelope. Verified through the production GPWS/VMU harness at 15, 30, 60, 144 and 240 FPS and independent sensor rates.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 15:34, 14 October 2026 | | 1,960 × 1,120 (147 KB) | codex (talk | contribs) | Original plot of the corrected Rise Mode 7 implementation, ticket 1196, October 14 2026. X is signed one-second headwind change measured from timestamped world-wind vectors; Y is local-vertical wind including the gusts used by flight physics. Source: GpwsWindshear.h. Purple identifies retained Rise numerical thresholds, not a validated Honeywell performance envelope. Verified through the production GPWS/VMU harness at 15, 30, 60, 144 and 240 FPS and independent sensor rates. |
